ProFace X[TI]
ProFace X [TI] is a fully upgraded version of the ProFace product line, which is designed to deal with all kinds of scenarios. Powered by the ZKTeco-customized CPU for running the intellectualized engineering facial recognition algorithm and the latest computer vision technology, ProFace X [TI] supports both facial and palm verification with large capacity and rapid recognition speed, boosting the security performance in all aspects.
ProFace X [TI] also helps eliminate hygiene concerns; not only because of the contactless recognition technology it is equipped with, but also because of the new functions namely body temperature detection and masked individual identification.
The facial recognition capability has reached a new height in the biometrics technology industry with a maximum of 50,000 facial templates, recognition speed of less than 0.3 sec per face, and ultimate anti-spoofing ability against almost all types of fake
photos and videos attack.
Faces 30,000 (1:N) / 50,000 (Optional)
Palm 5,000 (1:N), Users 50,000
Transactions 1,000,000
Mask detection / Body temperature detection
- Ultra-large capacity of facial templates for 1:N verification: 30,000 (standard); max. 50,000 (optional)
- Huge capacity of palm templates; 1:N – 5,000 palm templates
- Anti-spoofing algorithm against print attack (laser, color, and B/W photos), videos attack, and 3D mask attack
- Intelligent energy-saving design; precisely evaluation of the distance (up to 2.5m (8.2ft)) between the user and the device by a microwave detector before waking up the recognition terminal
- 2MP starlight CMOS sensor camera with WDR function
- 8” touch screen with 400 lux, which offers high visibility under strong and direct light
- Wide range of working temperature (16°C ~ 35°C; 60.8°F ~ 95°F)
- 0.1s High-Speed Temperature Detection, measurement distance of 30 – 120cm
- Temperature Measurement Accuracy: ±0.3°C (±0.54°F), tested in a distance of 80cm (2.63ft) under 25°C (77°F) environment
- Mask detection; facial verification available with masks
- Facial verification for masked individuals will increase FAR. Palm verification for masked individuals is recommended. Temperature measurement data is for reference only, not for medical use. ProFace X [TI] is available for indoor environments without wind or direct sunlight.
| Capacity | |
| Faces | 30,000 (1:N) / 50,000 (Optional) |
| Palm | 5,000 (1:N) |
| Users | 50,000 |
| Transactions | 1,000,000 / 2,000,000(Optional) |
| User Photos | 10,000 |
| Event Photos | 10,000 |
| Compatibility | Security Relay Box / Wiegand / RS485 / RS232 Slave Reader with FP / Barcode / QR-code / ZKBioSecurity and ZKBioAccess Software |
| Hardware | 900MHz Dual Core Customized Computer Vision CPU |
| 512MB RAM / 8G Flash | |
| 8″ High light (400lux) IPS Touch LCD | |
| 2MP WDR Low Light Camera | |
| Adjustable Light brightness LED / Hi-Fi Voice / High Sensitivity Microphone / Distance Detection Sensor / Reset Button and Tamper Switch | |
| Access Control Interface | Lock Relay Output / Alarm Output / Auxiliary Input / Exit Button / Door Sensor |
| Special Functions | 0.3s Hight Speed Facial Verification |
| Liveness Detection / HTTPS Communication Encryption (Optional) | |
| Event Snapshot | |
| Standard Functions: | Access Levels, Groups, Holidays, DST, Duress Mode (Password), Anti-Passback, Record Query, Tamper Switch Alarm, Custom Wallpaper & Screen Saver |
| Preventative Measures | Mask detection / Body temperature detection |
| Temperature Measurement Distance:30cm~120cm (0.98ft~3.94ft) | |
| Temperature Measurement Accuracy: ±0.3°C | |
| Temperature Measurement Range: 20°C~50°C(68°F ~ 122°F) | |
| Communication | TCP/IP / Wiegand Input / Output / Wi-Fi (Optional) / RS485 / RS232 |
| Additional Info | |
| Face Algorithm: | ZKLiveFace5.8 |
| Palm: | FAR ≤0.01%; FRR ≤1% |
| Working Temperature: | 16°C ~ 35°C,(60.8°F ~ 95°F) |
| Working Humidity: | ≤93% |
| Storage Temperature: | -40°C ~ 65°C (-40°F ~ 149°F) |
| Net Weight: | 853g |
| Dimensions (H*L*D): | 279*143*27mm |
| Power | |
| Operating Voltage: | 12V DC |
| Current Draw: | < 2,000mA |
